CEAM 1130 3D Concealed Hinge 40-60 kg Antique Brass Finish

SKU 32191.00.ABF

Availability: Loading...

£42.01

Excl. Tax: £35.01

Prices shown are Per Hinge

Size

134 mm

Finish

Antique Brass Finish Also available in Electro Brass Plated

Electro Brass Plated Also available in Imitation Bronze Lacquered

Imitation Bronze Lacquered Also available in Nickel Plated

Nickel Plated Also available in Satin Stainless Finish

Satin Stainless Finish Also available in Matt Black Finish

Matt Black Finish

Technical Information

Download Specification PDF

Unit of Measure	Per Hinge
Depth	21 mm
Height	134 mm
Width	24 mm

Description

CEAM 1130 3D Hinge
Concealed medium duty hinge for unrebated and rebated, flush-faced quality timber doors
Removable cover plates conceal adjustment screws

Maximum adjusted door weight:
With 2 hinges - 40 kg
With 3 hinges - 60 kg (middle hinge positioned 250mm below top hinge)
Load capacity refers to door H2100 x W850 mm

Three dimensionally adjustable
Vertical +/- 2.5 mm
Horizontal +/- 1 mm
Depth -1.5, +2.5 mm

Galvanized polyethylene plates completely cover the adjustment and clamping screws
Same mortise on door and frame
10 year guarantee
Suitable for half our fire door
Made from zinc alloy

30 min fire rating when used with intumescent see related products

Delivery

* Lead times are estimates only and start from the moment you place your order. They are based on current stock levels and supplier information, and can change. If you have any questions about product availability or lead times, please contact us before placing your order.

Delivery in U.K. Mainland is Free of Charge for orders over £125.00 excluding VAT.

All orders up to £125.00 excluding VAT will be delivered at a charge of £6.95 excluding VAT.

Can't wait for delivery or live locally?

You can place your order online, choose Click and Collect and then collect from our Showroom in Wimbledon Park, Monday to Friday 8am - 5pm. It's quick and easy with free parking on forecourt.

Returns

At SDS we want you to be happy with your order. If for any reason, you are unhappy with the items you have purchased return them to us and we will issue a full refund less any initial carriage charge.

Should you wish to return any items please review our returns procedures below.

Please note: Goods must be in their original packaging, unused and in a re-saleable condition. Once items have been fitted, these cannot be returned.

Customer Questions

Customer Questions

price per hinge or per pair?

Hi, thanks for your question. These hinges are sold as individual hinges.

Hi i’m wanting to verify if the ‘Satin Stainless Finish’ is referring to the Ceam Marine grade 304 stainless steel INOX model 1130. Seen here: https://www.ceamitalia.it/en/door-hinges/3d-concealed-door-hinges-1130-inox/

The Satin Stainless Steel finish is the finish only, the material still remains as brass. Should you need the INOX model, please get in touch with our sales team on 020 7228 1185 or email [email protected]
